70 MFD/UF- 440V - Single Run Capacitor - U.L. Rated - Two (2) - Poles/Posts with four terminal on each pole/post - 4 3/8" L w/terminals x 2 3/8" W - Will replace a 370V capacitor also. Made by Supco Corp.
Please note: Picture is Smart Electric brand but listing is Supco brand.
- Metalized polypropylene capacitors, encapsulated in an oil filled drawn steel seamless can with steel cover double rolled to provide a leakproof enclosure.
- U.L. registered internal current interrupter designed to disconnect the capacitor element if excessive pressure develops inside casing from misapplication.
- Terminals are provided with 4 blades surrounded by insulators to allow for quick installation.
- All weld connections (internal & external) are performed with single head electrodes.
- The dielectric fluid within each unit has the highest viscosity of any fluid used in A/C rated capacitors.
- Their compact size is due to a revolutionary method of winding that allows the highest capability of any film dielectric capacitor on the market.
